Technical Specifications
Dimensions: L×W×H 18000mm×4500mm×2300mm(Excluding air path and big blower room)
Glass thickness range : Tempering : 4- 19 mm
Glass size:
Max flat glass size : 2,440 mm x 3,660 mm 5-19mm
For 4mm, Max glass size: 2,440mm x1,500mm
Min glass size : 100 x 300 mm
Finished product rate: over 5mm not less than 98%.
Productivity / Process cycle time:
|
Thickness (mm) |
Common Flat Glass (load/h) |
Low-e Glass |
|
4 |
36-40 |
60%-70% of the common glass |
|
5 |
16-18 |
|
|
6 |
14-15 |
|
|
8 |
10-11 |
|
|
10 |
8-9 |
|
|
12 |
7-8 |
|
|
15 |
3-4 |
|
|
19 |
2-3 |
Installed power:
Heating : 550 kW
Drives : 12 kW
Flat Quenching : 250 KW x1
Convection blower: 4KW x3=12KW
Power requirement: Transformer no less than 500KW
Note: The power capacity may be different and should be referring to the actual
Compressed air(an air tank should be supplied with 0.5M3 at least) :
Volume : 0.6-0.8m3 /min
Pressure : >0.7 MPa
Suitable glass sorts:
Clear float glass
Coated glasses
Low-e glass(e value 0.15-0.02)
Patterned glass
Tinted glass
Supply Scope
-- Loading table
-- Heating section (furnace)
-- Flat Quenching section
-- Unloading table
-- Associated electrical and control equipment
-- Control terminal
— Remote diagnosis system
--250KW inverter*1
Luoyang Easttec Glass Automation Equipment Co., Ltd. established in 2006, is a high-tech enterprise specializing in the design, manufacture and sales of glass thermal processing equipment. Easttec has a group of professional technicians engaged in glass deep-processing equipment design and manufacture for more than twenty years. And with rich experience, ongoing innovation, exquisite design, and the advantages drawn from Eupopean companies, the company manufactures new glass processing equipment with excellent quality, reliable performance and reasonable price.
